DBX1000M Recessed Metal Dryer Vent Box with Trim Ring

$48.00 USD

Sale Sold out

Model/Wall DBX1000M-6 – 5" Deep (2x6 Walls) DBX1000M-4 – 3½" Deep (2x4 or 2x6 Walls)

BUY MORE & SAVE

Buy 2 → FREE Shipping

Buy 3+ → Save 5% + FREE Shipping

5% discount automatically applied in cart.

Buying in bulk or purchasing for a project? Request contractor & quantity pricing.

Professional-Grade Recessed Metal Dryer Vent Box

The DBX1000M Recessed Metal Dryer Vent Box provides a clean, durable in-wall connection for clothes dryer exhaust systems. Constructed from 22-gauge powder-coated steel, it recesses the dryer duct connection into the wall to help reduce space behind the dryer and create a professional finished installation.

Contractor & Project Quantities

Purchasing DBX1000M dryer boxes for a multifamily, home builder, or large HVAC project?

Solid Source HVAC supports high-volume project orders with:

Project and contractor quantity pricing
Phased material releases
Jobsite or warehouse delivery coordination
Shipment and tracking updates
Support from initial quote through final delivery

Large project quantities from $32.00 each*

Whether you need the entire order delivered at once or material released in phases as construction progresses, we can help coordinate your DBX1000M order around your project requirements.

Get Project Pricing →

*Project pricing varies by model, quantity, freight, and delivery requirements.

Important for 2x4 walls: The DBX1000M-4 uses an intentionally oval-shaped duct opening so a standard 4" dryer duct can fit within the limited depth of a 2x4 wall cavity.

Available for 2x4 and 2x6 wall construction, the DBX1000M supports multiple venting configurations and includes a snap-on trim ring for a clean finished appearance. Designed for residential, multifamily and commercial laundry installations.

Choose Your DBX1000M Model

DBX1000M-4 – 3½" Deep: Designed for 2x4 framing and can also be installed in 2x6 framing. The duct opening is intentionally oval-shaped to allow a standard 4" dryer exhaust duct to fit within the limited depth of a 2x4 wall cavity. This is a design feature, not a defect.
DBX1000M-6 – 5" Deep: Designed specifically for 2x6 framing and provides additional depth for the 4" dryer exhaust connection.
Both models: Constructed from 22-gauge steel with a white powder-coated finish and snap-on trim ring.

Important – DBX1000M-4 Duct Opening:
The DBX1000M-4 has an oval-shaped 4" duct connection by design. Because a nominal 2x4 wall cavity is only 3½" deep, the connection is formed into an oval profile to accommodate standard 4" dryer duct within the wall cavity.

Technical Specifications
